Uwagi do procesora: Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max, Technology 3.0, Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types
Uwagi do pamięci RAM: Supports Intel® Extreme Memory Profile (XMP), OptiMem II, Supported memory types, data rate (speed), and number of DRAM modules vary, depending on the CPU and memory configuration, For more information please refer to CPU/Memory Support under the
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10,5 + 3x M.2
Uwagi do kontrolera SATA: Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports, Intel® 13th & 12th Gen Processors:, M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), Intel® B760 Chipset, M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10
Wbudowana karta graficzna: Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: Graphics specifications may vary between CPU types., Supports 4K@60Hz as specified in HDMI 2.1., Supports max. 4K@60Hz as specified in DisplayPort 1.4., VGA resolution support depends on processors' or graphic cards' resolution
Zintegrowana karta dźwiękowa: ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Gniazda karty dźwiękowej: 5x Audio Jack, Wewnętrzne gniazdo S/PDIF Out
Uwagi do karty dźwiękowej: - Impedance sense for front and rear headphone outputs, - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, - High quality 120 dB SNR stereo playback output and 113 dB SNR recording, input, - Supports up to 32-Bit/384 kHz playback, Audio Features:, - SupremeFX Shielding Technology, - Savitech SV3H712 AMP, - Premium audio capacitors, - Dedicated audio PCB layers, - Audio cover, The rear panel Line out port does not support spatial audio. If you wish to, use spatial audio make sure to connect your audio output device to the, audio jack on the front panel of your chassis
Złącza PCI Express x16: 2
Złącza PCI Express x1: 2
Uwagi do złącz PCI: 1 x PCIe 5.0 x16 slot, 1 x PCIe 3.0 x16 slot (supports x4 mode), 2 x PCIe 3.0 x1 slots, PCIe x1(G3)_1 and PCIe x1(G3)_2 slots share bandwidth with PCIe x16(G3), When PCIe x1(G3)_1 or PCIe x1(G3)_2 slot is operating, PCIe x16(G3) will, only supports x2 mode, To ensure compatibility of the device installed, please refer to
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Intel®)
Uwagi do karty sieciowej: ASUS LANGuard / TUF LANGuard
Maksymalna ilość portów USB 2.0: 7
Maksymalna ilość portów USB 3.x: 8
Porty USB na panelu tylnym: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type-C + 1x USB 3.1 + 1x USB 3.2 Type-C
Gniazda USB na płycie głównej: 2x USB 2.0 (3 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 (1 port)
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth: Bluetooth V5.3
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: 4-pin CPU OPT Fan header, 4-pin AIO Pump header, 3x Addressable Gen 2 header, AURA RGB header, Thunderbolt™ (USB4®) header
Wyposażenie dodatkowe: 2x SATA 6Gb/s cables, Additional Cooling Kit, Thermal pad for M.2, ASUS Wi-Fi moving antennas, Cable ties package, M.2 Q-Latch package, ROG key chain, ROG Strix stickers, ROG Strix thank you card, M.2 Rubber, Packages, User guide
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Wi-Fi 6: 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax), Supports 2.4/5/6GHz frequency band, WiFi 6E 6GHz regulatory may vary between countries, The Bluetooth version may vary, please refer to the Wi-Fi module, manufacturer's website for the latest specifications, Manageability: WOL by PME, PXE, Operating System: Windows® 11, Windows® 10 64-bit
Parametry:
Zawiera baterię / akumulator:
Tak
Wyposażenie dodatkowe:
2x SATA 6Gb/s cables, Additional Cooling Kit, Thermal pad for M.2, ASUS Wi-Fi moving antennas, Cable ties package, M.2 Q-Latch package, Packages, User guide, ROG key chain, ROG Strix stickers, ROG Strix thank you card, M.2 Rubber
Opakowanie:
BOX
Format płyty:
ATX
Wymiary [S x W] (mm):
305 x 244
Maksymalna wielkość pamięci:
128 GB
Port LAN:
1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Intel®)
Port Wi-Fi:
IEEE 802.11a/b/g/n/ac/ax
Port Bluetooth:
Bluetooth V5.3
Wbudowana karta graficzna:
Brak lub Intel® UHD Graphics 730/750/770/Iris Xe (zależy od procesora)
Intel® Turbo Boost Max Technology 3.0 support depends on the CPU types, Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max, Technology 3.0
BIOS:
256 Mb Flash ROM, UEFI AMI BIOS
Ilość złącz pamięci DDR4:
4
Tryb pracy pamięci RAM:
Dual Channel
Uwagi do pamięci RAM:
depending on the CPU and memory configuration, For more information please refer to CPU/Memory Support under the, OptiMem II, Supported memory types, data rate (speed), and number of DRAM modules vary, Supports Intel® Extreme Memory Profile (XMP)
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,10,5 + 3x M.2
Uwagi do kontrolera SATA:
Intel® 13th & 12th Gen Processors:, Intel® B760 Chipset, Intel® Rapid Storage Technology supports SATA RAID 0/1/5/10, M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode), M.2_3 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode), Total supports 3 x M.2 slots and 4 x SATA 6Gb/s ports
Gniazda karty graficznej:
DisplayPort, HDMI
Uwagi do karty graficznej:
Graphics specifications may vary between CPU types., Supports 4K@60Hz as specified in HDMI 2.1., Supports max. 4K@60Hz as specified in DisplayPort 1.4., VGA resolution support depends on processors' or graphic cards' resolution
Zintegrowana karta dźwiękowa:
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080
Gniazda karty dźwiękowej:
5x Audio Jack, Wewnętrzne gniazdo S/PDIF Out
Uwagi do karty dźwiękowej:
- Audio cover, - Dedicated audio PCB layers, - High quality 120 dB SNR stereo playback output and 113 dB SNR recording, - Impedance sense for front and rear headphone outputs, - Premium audio capacitors, - Savitech SV3H712 AMP, - Supports up to 32-Bit/384 kHz playback, - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking, - SupremeFX Shielding Technology, Audio Features, audio jack on the front panel of your chassis, input, The rear panel Line out port does not support spatial audio. If you wish to, use spatial audio make sure to connect your audio output device to the
Złącza PCI Express x16:
2
Złącza PCI Express x1:
2
Uwagi do złącz PCI:
1 x PCIe 3.0 x16 slot (supports x4 mode), 1 x PCIe 5.0 x16 slot, 2 x PCIe 3.0 x1 slots, only supports x2 mode, PCIe x1(G3)_1 and PCIe x1(G3)_2 slots share bandwidth with PCIe x16(G3), To ensure compatibility of the device installed, please refer to, When PCIe x1(G3)_1 or PCIe x1(G3)_2 slot is operating, PCIe x16(G3) will
Uwagi do karty sieciowej:
ASUS LANGuard / TUF LANGuard
Maksymalna ilość portów USB 2.0:
7
Maksymalna ilość portów USB 3.x:
8
Porty USB na panelu tylnym:
4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type-C + 1x USB 3.1 + 1x USB 3.2 Type-C
Gniazda USB na płycie głównej:
2x USB 2.0 (3 porty) + 1x USB 3.0 (2 porty) + 1x USB 3.1 (1 port)
Port PS/2:
Brak
Port szeregowy (COM):
Brak
Port równoległy (LPT):
Brak
Inne porty i gniazda:
3x Addressable Gen 2 header, 4-pin AIO Pump header, 4-pin CPU OPT Fan header, AURA RGB header, Thunderbolt™ (USB4®) header
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin) + ATX12V (4-pin)
Dane producenta
ASUSTeK Computer Inc.
1F.,No.15,Llde Rd.,Beitou Dist
112 Taipei City
Taiwan
