Uwagi do pamięci RAM: Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2
Uwagi do kontrolera SATA: CPU:, - 1 x M.2 connector (Socket 3, M key, type 2280, PCIe 5.0 x4/x2 SSD support)(M2A_CPU), Chipset:, - 1 x M.2 connector on the back of the motherboard (Socket 3, M key,, type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB), - 2 x SATA 6Gb/s connectors
Uwagi do karty graficznej: - 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port),supporting, DisplayPort and Thunderbolt™ video outputs, - When a Thunderbolt monitor is installed, the maximum resolution, supported is 5120x2880@60 Hz with 24 bpp (single display output), - When a USB4 USB Type-C monitor is installed, the maximum resolution, supported is 3840x2160@240 Hz (single display output), - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, Support for DisplayPort 2.1 version and HDCP 2.3, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, Support for HDMI 2.1 version and HDCP 2.3
Zintegrowana karta dźwiękowa: Realtek® HD Audio CODEC
Uwagi do karty dźwiękowej: High Definition Audio, 2/4/5.1/7.1-channel
Złącza PCI Express x16: 1
Uwagi do złącz PCI: CPU:, - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, - The PCIEX16 slot can only support a graphics card or an NVMe SSD
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 2
Maksymalna ilość portów USB 3.x: 8
Maksymalna ilość portów USB 4.0: 1
Porty USB na panelu tylnym: 2x USB 3.0 + 3x USB 3.1 + 1x Thunderbolt 4/USB4 (USB Type-C)
Gniazda USB na płycie głównej: 2x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 Type-C
Port Wi-Fi: IEEE 802.11a/b/g/n/ac/ax/be
Port Bluetooth: Bluetooth V5.4
Uwagi do WiFi / BT: Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.0), - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency, bands, - BLUETOOTH 5.4, - Support for 11be 320MHz wireless standard, MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.1), - 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency, bands, - BLUETOOTH 5.4, - Support for 11be 160MHz wireless standard, - Actual data rate may vary depending on environment and equipment, - Wi-Fi 7 features require Windows 11 SV3 to function properly, - Wi-Fi 7 channels on 6 GHz band availability depends on country's, regulations
Port PS/2: Brak
Port szeregowy (COM): Brak
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, CPU fan/water cooling pump header, System fan header, 2x Addressable LED strip headers, Front panel header, Front Panel Audio header (AAFP), Speaker header, Trusted Platform Module header, Reset jumper, Clear CMOS jumper, 2x SMA antenna connectors (2T2R)
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 170 x 170
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Norton® Internet Security (OEM version), LAN bandwidth management software, Support for Windows 11 64-bit, BIOS: PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
(operate in non-ECC mode), Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Zintegrowany kontroler SATA:
Chipset+CPU: 2x SATA III 6Gb/s - RAID 0,1 + 2x M.2
Uwagi do kontrolera SATA:
- 1 x M.2 connector (Socket 3, M key, type 2280, - 1 x M.2 connector on the back of the motherboard (Socket 3, M key,, - 2 x SATA 6Gb/s connectors, Chipset:, CPU:, PCIe 5.0 x4/x2 SSD support) (M2A_CPU), type 2280 PCIe 4.0 x4/x2 SSD support) (M2Q_SB)
Gniazda karty graficznej:
DisplayPort, HDMI, Thunderbolt™ 4
Uwagi do karty graficznej:
- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - 1 x Intel® Thunderbolt™ 4 connector (USB4® USB Type-C® port),supporting, - When a Thunderbolt monitor is installed, the maximum resolution, - When a USB4 USB Type-C monitor is installed, the maximum resolution, DisplayPort and Thunderbolt™ video outputs, Support for DisplayPort 2.1 version and HDCP 2.3, Support for HDMI 2.1 version and HDCP 2.3, supported is 3840x2160@240 Hz (single display output), supported is 5120x2880@60 Hz with 24 bpp (single display output)
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, - The PCIEX16 slot can only support a graphics card or an NVMe SSD, CPU:
Maksymalna ilość portów USB 2.0:
2
Maksymalna ilość portów USB 3.x:
8
Porty USB na panelu tylnym:
2x USB 3.0 + 3x USB 3.1 + 1x Thunderbolt 4/USB4 (USB Type-C)
Gniazda USB na płycie głównej:
2x USB 2.0 + 2x USB 3.0 + 1x USB 3.1 Type-C
Port PS/2:
Brak
Port szeregowy (COM):
Brak
Port równoległy (LPT):
Brak
Inne porty i gniazda:
2x Addressable LED strip headers, 2x SMA antenna connectors (2T2R), Clear CMOS jumper, CPU fan header, CPU fan/water cooling pump header, Front Panel Audio header (AAFP), Front panel header, Reset jumper, Speaker header, System fan header, Trusted Platform Module header
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Uwagi do WiFi / BT:
- 802.11a, b, g, n, ac, ax, be, supporting 2.4/5/6 GHz carrier frequency, - Actual data rate may vary depending on environment and equipment, - BLUETOOTH 5.4, - Support for 11be 160MHz wireless standard, - Support for 11be 320MHz wireless standard, - Wi-Fi 7 channels on 6 GHz band availability depends on country's, - Wi-Fi 7 features require Windows 11 SV3 to function properly, bands, MediaTek Wi-Fi 7 MT7925 (PCB rev. 1.1), Realtek® Wi-Fi 7 RTL8922AE (PCB rev. 1.0), regulations
Ilość złącz pamięci DDR5:
2
Maksymalna ilość portów USB 4.0:
1
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
