Uwagi do pamięci RAM: Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, (operate in non-ECC mode), Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules, Support for Extreme Memory Profile (XMP) memory modules
Zintegrowany kontroler SATA: Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 2x M.2
Uwagi do kontrolera SATA: CPU:, - 1 x M.2 connector (Socket 3, M key, type 2280, PCIe 4.0 x4/x2 SSD support)(M2A_CPU), Chipset:, - 1 x M.2 connector (Socket 3, M key, type 2280, PCIe 4.0 x4/x2 SSD support)(M2Q_SB), - 4x SATA 6Gb/s connectors
Gniazda karty graficznej: HDMI, DisplayPort
Uwagi do karty graficznej: - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - Support for HDMI 2.1 version and HDCP 2.3, - 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, - Support for DisplayPort 2.1 version
Zintegrowana karta dźwiękowa: Realtek® HD Audio CODEC
Uwagi do karty dźwiękowej: High Definition Audio, 2/4/5.1/7.1-channel
Złącza PCI Express x16: 3
Uwagi do złącz PCI: CPU:, - 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, - The PCIEX16 slot can only support a graphics card or an NVMe SSD, Chipset:, - 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
Port LAN: 1x 2,5 Gigabit LAN 100/1000/2500 Mb/s (Realtek®)
Maksymalna ilość portów USB 2.0: 7
Maksymalna ilość portów USB 3.x: 6
Porty USB na panelu tylnym: 3x USB 2.0 + 3x USB 3.0
Gniazda USB na płycie głównej: 4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type-C
Port PS/2: Port combo klawiatury/myszy PS/2
Port szeregowy (COM): 1x wewnętrzne gniazdo portu COM
Port równoległy (LPT): Brak
Inne porty i gniazda: CPU fan header, CPU fan/water cooling pump header, System fan header, System fan/water cooling pump extension cable header, 2x Addressable RGB Gen2 LED strip header, RGB LED strip header, Front panel header, Front Panel Audio header (AAFP), Trusted Platform Module header, Clear CMOS jumper
Gniazdo zasilania: ATX (24-pin) + ATX12V (8-pin)
Wymiary [S x W] (mm): 244 x 244
Opakowanie: BOX
Zawiera baterię / akumulator: Tak
Informacje dodatkowe: Norton® Internet Security (OEM version), LAN bandwidth management software, Support for Windows 11 64-bit, Support for Windows 10 64-bit, BIOS: PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
(operate in non-ECC mode), Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules, Support for Extreme Memory Profile (XMP) memory modules, Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Zintegrowany kontroler SATA:
Chipset+CPU: 4x SATA III 6Gb/s - RAID 0,1,5,10 + 2x M.2
Uwagi do kontrolera SATA:
- 1 x M.2 connector (Socket 3, M key, type 2280, - 4 x SATA 6Gb/s connectors, Chipset:, CPU:, PCIe 4.0 x4/x2 SSD support) (M2A_CPU), PCIe 4.0x4/x2 SSD support) (M2Q_SB)
Gniazda karty graficznej:
DisplayPort, HDMI
Uwagi do karty graficznej:
- 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz, - 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz, - Support for DisplayPort 2.1 version, - Support for HDMI 2.1 version and HDCP 2.3
- 1 x PCI Express x16 slot, supporting PCIe 5.0 and running at x16, - 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1, - The PCIEX16 slot can only support a graphics card or an NVMe SSD, Chipset:, CPU:
Maksymalna ilość portów USB 2.0:
7
Maksymalna ilość portów USB 3.x:
6
Porty USB na panelu tylnym:
3x USB 2.0 + 3x USB 3.0
Gniazda USB na płycie głównej:
4x USB 2.0 + 2x USB 3.0 + 1x USB 3.0 Type-C
Port PS/2:
Port combo klawiatury/myszy PS/2
Port szeregowy (COM):
1x wewnętrzne gniazdo portu COM
Port równoległy (LPT):
Brak
Inne porty i gniazda:
2x Addressable RGB Gen2 LED strip header, Clear CMOS jumper, CPU fan header, CPU fan/water cooling pump header, Front Panel Audio header (AAFP), Front panel header, RGB LED strip header, System fan header, System fan/water cooling pump extension cable header, Trusted Platform Module header
Gniazdo zasilania:
ATX (24-pin) + ATX12V (8-pin)
Ilość złącz pamięci DDR5:
4
Dane producenta
Gigabyte Technology Co. Ltd.
NO. 6, BAO CHIANG ROAD
231 Xindian Dist., New Taipei
Taiwan
